DEGSON 2EDG-STD-5.0/5.08 PLUGGABLE TERMINAL BLOCK

180 / 310

Quantity

Add Quotation

Item	Data
APPROVAL
Test standard	IEC61984：2009 / UL1059
Pitch [mm]	5.0/5.08
Poles	02-24P
IEC61984 Test data	-
Rated voltage [V]	250
Rated current [A]	24
Rated connection capacity(solid/stranded) [mm²]	1.0~2.5
Surge voltage category/pollution degree/material group	III/2/I
Rated impulse voltage [KV]	4
Rated torque [N·m]	0.4
UL1059Test data	UL File Number E228872
Use group	B	C	D
Rated voltage [V]	300	/	300
Rated current [A]	15	/	10
(Rated connection capacity) (solid/stranded) [AWG]	28-Dec
Rated torque [Lb. in]	3.54
General data	/
Screw	M2.5
Inflammability classUL94	V-0
Ambient temperature [℃]	-40~+105
Relative humidity	5%-95%
Inspection standard	MIL-STD-105E II
AQL	0.65
Warranty	12 months
Material and plating	/
Housing	PA66
Screws	Steel，Zn plated
Contact	Copper alloy，Sn plated
Cage	Copper alloy，Ni plated
Wire connecting
8-9mm; Recommended stripping length 8-9mm;
1.）For solid wire, stripping wire to the appointed length, then tightening with rated torque.
2.）For stranded wire: stripping wire to the appointed length, mating with corresponding type of ferrule, then tightening with rated torque.
Tightening process should be steady, can’t use explosive force.
